Flexible Polyamide Nylon PA Tube

China Flexible Polyamide Nylon PA Tube supplier
Flexible Polyamide Nylon PA Tube supplier Flexible Polyamide Nylon PA Tube supplier Flexible Polyamide Nylon PA Tube supplier

Large Image :  Flexible Polyamide Nylon PA Tube

Product Details:

Place of Origin: China
Brand Name: B&C
Certification: SGS,UL, CE,IOS9001,ISO14001
Model Number: Nylon PA rod -001
Size: O.D.3mm to O.D.20mm Length: 25m,30m,50m,100 m.

Payment & Shipping Terms:

Minimum Order Quantity: 50metres
Price: Negotiable
Packaging Details: Ply-Wooden Cases
Delivery Time: 10-20days
Payment Terms: T/T, LC
Supply Ability: 110Tons/month
Contact Now
Detailed Product Description
Temperature: -40°C - 120°C Type: Nylon PA Tube
Applications: Machinery Building Feature: Flexible
Material: Polyamide Product Name: Industrial Engineering Plastics



Flexible Industrial Engineering Plastics , Polyamide Nylon PA Tube For Machinery Building



Quick Detail:



1.Good wear ability, smooth surface, low resistance, anti-rustiness and anti-scaling

2.Flexible, easy to be bended into all kinds of shapes , easy to install

3.High chemical and hydrolysis resistance, stable dimension

4.High and low temperature resistance(-40°C~120°C),can transfer compressed air, water,oil, chemical

   liquid and so on.

5.It is widely used in Light trucks, car hydraulic brake system,power steering tube, and so on.





Description:



Nylon PA tube is a strong, stiff engineering plastic with outstanding bearing and wears properties. Nylon is

frequently used to replace metal bearings and bushings often eliminating the need for external lubrication.

PA tube is recognized as the most widely used and known engineering plastic on the market and for good

reason. Nylon tube has Good wear ability, smooth surface, low resistance, anti-rustiness and anti-scaling,

and so on.







Applications:



Nylon tube can widely use as

1.Machinery building,

2.electrical insulating protection,

3.illuminating equipment,

4.automobile manufacturing,

5.flight equipments,

6.metro,

7.trains and automatic control, etc.





Specifications:



Material

Polyamide

Fluid

air,water

Burst Pressure

60 bar

Operation pressure

>20bar

Operating Temp

-20째C - +80째C



Mode  No.

Size(O.D×Wall)

 O.D.(mm)

Thickness(mm)

Work pressure(Mpa) BurstPressure(Mpa)

BC1

3×0.5

3

0.5

3

4.5

BC2

4×0.75

4

0.75

3.1

5.5

BC3

4×1

4

1

4.5

6.8

BC4

5×1

5

1

3.4

6.5

BC5

6×1

6

1

3.2

6.3

BC6

8×1

8

1

2.6

5.7

BC7

10×1

10

1

2.7

4.5

BC8

10×1.25

10

1.25

2.8

5.6

BC9

12×1.5

12

1.5

3.2

5.7

BC10

14×1.5

14

1.5

2.2

5.6

BC11

15×1.5

15

1.5

2

5.4

BC12

16×2

16

2

2.8

5.4

BC13

18×1.5

18

1.5

2.3

3.6





Remarks:



We can also produce Nylon PA tube in other sizes according to customer's specific requirements.





Competitive Advantage:



1.Excellent Chemical property

2.Virgin and recycled materials available

3.Any sizes available

4.Fast Usually
