Oil Resistance / Anti-Corrosion Fluoropolymer Resin PFA Resin For Steam Pipe

China Oil Resistance / Anti-Corrosion Fluoropolymer Resin PFA Resin For Steam Pipe supplier
Oil Resistance / Anti-Corrosion Fluoropolymer Resin PFA Resin For Steam Pipe supplier Oil Resistance / Anti-Corrosion Fluoropolymer Resin PFA Resin For Steam Pipe supplier

Large Image :  Oil Resistance / Anti-Corrosion Fluoropolymer Resin PFA Resin For Steam Pipe

Product Details:

Place of Origin: China
Brand Name: B&C
Certification: SGS,UL, CE,IOS9001,ISO14001
Model Number: PFA resin-002

Payment & Shipping Terms:

Minimum Order Quantity: 150KGS
Price: Negotiable
Packaging Details: Ply-Wooden Cases
Delivery Time: 10-20days
Payment Terms: T/T, LC
Supply Ability: 110Tons/month
Contact Now
Detailed Product Description
High Light:

PFA Resin

,

FEP Resin

Oil Resistance / Anti-Corrosion Fluoropolymer Resin PFA Resin For Steam Pipe





Quick Detail:



A. aging resistance

B. radiation resistance

C. low permeability

D. high pressure resistance

E. oil resistance

F.  anti-corrosion

G. Flame retardation.







Description:



PFA resin its chemical stability properties, physical and mechanical performance,

electrical insulating properties, lubricity, not sticky, aging and incombustible are very fine, all and assembled

tetrachloroethylene similar. Also has the same tetrachloroethylene and assembled the thermal stability,

PFA resin is suitable for electrical and electronic industry insulating layer, high frequency and uhf wire

insulation, electronic devices, insulation parts cable insulation and sheath, connector plug,bearing

insulation, printed circuit boards, electrostatic megaphone to use membrane, etc. Especially the small

size thin-wall insulation line, its processing speed is more then general PTFE twined materials many times







Applications:



PFA resins can widely used in:



1. Heat exchanger,

2. Steam pipe,

3. High purity reagent pipeline,

4. All kinds of corrosive medium (harsh solvents) pipe,

5. Wiring insulation jacket.

6. Detailed fluorine rubber ring plastic pipe.

7. Ultra high frequency electrical wiring insulation,

8. Electronic devices,

9. The connector plug,







Technical Parameter:



Physical performance

Proportion(g/CM3)

2.12-2.17

Melting Point(°C)

302-312

Melt Index(g/10min)

15-17



Mechanical properties

Tensile Strength (MPa)

27-29

Elongation at break(%)

300

hardness

60

coefficient of dynamic friction

0.04

Thermal properties

Continuous highest use temperature(°C)

82~260

HDT (°C) (18.5kg/cm2)

12

coefficient of linear expansion*105(K-1)

15

Electric performance

Volume resistance(Ω·CM)

1018

Insulation destruction voltage (0.2mm)(MV/m)

20

Permitting(1KHz)

2.1

Dielectric Loss Tangent(tanδ)(X106Hz)

≤0.03







Remarks:



You may interested in our other products just like PVDF resin,FEP resin and PTFE resin, etc.







Competitive Advantage:



1.Excellent Chemical property

2.Virgin and recycled materials available

3.Any sizes available

4.Fast Usually





Item

Unit

BC001

BC002

BC003

BC004

A

B

C

Appearance



Translucent particles



MFR

g/10min

0.8-2

2.1-6

6.1-12

12.1-16

16.1-24

24.1-30

Density ratio

g/cm3

2.10-2.16

2.10-2.16

2.10-2.16

2.10-2.16

2.10-2.16

2.10-2.16

Melting temperature

300-310

300-310

300-310

300-310

300-310

300-310

Operating temperature

260

260

260

260

260

260

Tensile strength

Mpa

33-36

30-35

28-32

28-32

28-32

28-32

(23℃),≥

Elogation at break

%

300

300

300

300

300

300

(23℃)

Water absorption,<

0.1

0.1

0.1

0.1

0.1

0.1







Product usage:



BC001: Mainly used for piping, pump, valve, tank lining, diaphragm, joint part, bearing, etc;

BC002: Mainly used for pipe, wire insulation layer, thin films, and various parts;

BC003: Used for general-purpose plastics extrusion processing, mainly used for cable insulation wire,

             multiconductor cable sheath, etc.;

BC004:Mainly used in aviation, aerospace industry, chemical industry,used for faster cabel extrusion,

    and it is more economical for most purposes without stress cracking resistance.
