Clear PTFE FEP Film Insulation Chemical Resistance / FEP Shrink Tubing
FEP film is used for applications requiring optical clarity, quick release, and abrasion resistance. The FEP backing offers excellent high temperature resistance and offers the highest electrical strength in volts
per mil. FEP backingis chemically inert, thin and conformable. The tape construction is weather resistant,
stable and non-toxic.
FEP film applications include high temperature coil and capacitor wrapping, composite bonding, masking,
and conveyor release linings.
|
Grades |
Thickness |
Size & Weight per Roll |
|||
|
(μm) |
(mils) |
Width(mm) |
Length(m) |
Weight(kg) |
|
|
BC-0012 |
12.5 |
0.5 |
1150 |
200 |
6 |
|
BC-0025 |
25 |
1 |
1150 |
200 |
12.5 |
|
BC-0050 |
50 |
2 |
1150 |
200 |
25 |
|
BC-0100 |
100 |
4 |
1150 |
100 |
25 |
|
BC-0250 |
250 |
10 |
1250 |
80 |
50 |
|
BC-0500 |
500 |
20 |
1250 |
40 |
50 |
|
BC-1000 |
1000 |
40 |
1250 |
20 |
50 |
|
BC-1500 |
1500 |
60 |
1250 |
25 |
100 |
|
BC-2400 |
2400 |
95 |
1250 |
15 |
100 |
